HP 3D Structured Light Scanner Pro S2 (911005-002)

(No reviews yet) Write a Review

SKU:

911005-002-n

UPC:

190780863695

MPN:

911005-002

Description
Warranty Information

Description

Overview:

The HP Structured Light Scanner Pro S2 (ex- DAVID SLS-2) is a professional-level 3D solution using structured light technology based on a combination of hardware, software and accessories. Today, digital animators, archivists, archaeologists, biomedical researchers, jewelry designers, product designers and many more professions are using this amazing 3D scanner for reverse engineering, physical model conversion or artifact reproduction.

The HP 3D Structured Light Scanner Pro S2 provides 360°, “water-tight”, 3D scans in seconds with easy single click scanning. The modular hardware setup allows a flexible adaptation to your object - any size from coin to couch is possible!

System requirements
• Windows® OS (64 bit – Windows Vista, 7, 8, 10)
• 3D graphics adapter
• Available VGA or HDMI port
• Two available USB ports
• Microsoft .NET Framework 4.6 (included on the USB flash drive)
• Recommended: Dual-core 2GHz processor, 64bit Windows, 8 GB RAM, 1GB NVIDIA or AMD graphics card

Technical specification
• Resolution/precision: up to 0.05% of scan size (up to 0.05mm)
• Scanning time: One single scan within 2 seconds (or up to -10 seconds, depending on settings and computer speed)
• Scan Size 60-500 mm
• Mesh density: Up to 1,200,000 vertices per scan
• Export formats: OBJ, STL, PLY

Product features:

USB CMOS camera and high quality lens
Video projector with special lens for large focal range
USB Dongle with HP 3D Scan Software Pro v5
Rail, camera slider, high quality tripod and all necessary power and connecting cables
Calibration panels printed on both sides for multiple scan volumes
